PIC16C73B-04/SP
28핀,4MHz,4K프로그램메모리,DIP타입
판매가격 : 3,360
적립금 :34
상품상태 :신상품
제품코드 :1058595
제조사 :MICROCHIP
출시일 :2018-02-07
구매수량 :
총 금액 :
MCU이용 꿀팁

8,640원
13,200원
6,960원
2,760원
6,480원
132,000원
72,000원
11,400원
5,400원
3,600원
상세정보 배송/취소/교환안내 이용후기 상품Q&A

PIC16C73B-04/SP

Features

  • PIC16CXX Microcontroller Core Features
  • • High performance RISC CPU
    • Only 35 single word instructions to learn
    • All single cycle instructions except for program branches which are two cycle
    • Operating speed:
      DC - 20 MHz clock input
      DC - 200 ns instruction cycle
    • 4 K x 14 words of Program Memory, 192 x 8 bytes of Data Memory (RAM)
    • Interrupt capability
    • Eight-level deep hardware stack
    • Direct, indirect and relative addressing modes
    • Power-on Reset (POR)
    • Power-up Timer (PWRT) and Oscillator Start-up Timer (OST)
    • Watchdog Timer (WDT) with its own on-chip RC oscillator for reliable operation
    • Programmable code protection
    • Power-saving SLEEP mode
    • Selectable oscillator options
    • Low power, high speed CMOS EPROM technology
    • Wide operating voltage range: 2.5V to 5.5V
    • High Sink/Source Current 25/25 mA
    • Commercial, Industrial and Automotive temperature ranges
    • Low power consumption:
    - < 5 mA @ 5V, 4 MHz
    - 23 ㎂ typical @ 3V, 32 kHz
    - < 1.2 ㎂ typical standby current


  • PIC16C7X Peripheral Features
  • • Timer0: 8-bit timer/counter with 8-bit prescaler
    • Timer1: 16-bit timer/counter with prescaler can be incremented during SLEEP via external crystal/clock
    • Timer2: 8-bit timer/counter with 8-bit period register, prescaler and postscaler
    • Capture, Compare, PWM modules
    - Capture is 16-bit, max. resolution is 200 ns
    - Compare is 16-bit, max. resolution is 200 ns
    - PWM max. resolution is 10-bit
    • 8-bit multichannel Analog-to-Digital converter
    • Synchronous Serial Port (SSP) with SPI™ and I2C™
    • Universal Synchronous Asynchronous Receiver Transmitter (USART/SCI)
    • Parallel Slave Port (PSP), 8-bits wide with external RD, WR and CS controls
    • Brown-out detection circuitry for Brown-out Reset (BOR)



Ordering Information

  • Package Type : 28-Lead PDIP
  • Operating temperature : 0℃ ≤ TA ≤ +70℃ for commercial



※ 공급 제조사는 재고 사정에 따라 동일 사양의 대체상품으로 공급될 수 있습니다.
※ 상기 제품에 첨부된 데이타시트는 참고사항입니다.데이타시트에 표기된 내용에 대하여 본사는 어떠한 기술적인 문의 및 발생하는 문제에 대한 법적인 책임을 지지는 않습니다.
※ 사용자께서는 사용 전 반드시 제품에 대한 테스트 및 확인 절차 후 사용하시기 바랍니다
